QuickShifter easy
Supplementary Manual
Honda CB1000R ABS 2008- (iQSE-W1 + QSH-P2T)
www.healtech-electronics.com 3/3
Mount the QSE sensor.
(Replace the bolt with the one supplied.
Place the conical washers at the two sides
of the sensor like this: (0). Tighten the bolt
in this position by about 6 Nm. If you do not
have torque wrench, tighten the bolt until
the shift arm is tight on the gearbox shaft.)
Typical position for the QuickShifter easy.
Secure the unit properly.
