7.3 Mechanical Parameters
Dimensions 55 x 55 x 7 mm
Weight 34 g
Cable length charging cables 0.15 m
Cable length electrode cables 96 cm (REF: 108-4062)
Output socket 2 x 2 mm pin
Input socket USB-Type B micro
7.4 Environmental Conditions
7.4.1 Operation and Storage
Temperature Range 5°C to 40°C / 41°F to 104°F
Relative humidity 30 % to 80 %
Atmospheric pressure 700 hPa to 1060 hPa
7.5 Stimulation Settings (Standard Programs)
The waveform is always a biphasic rectangle. One phase is de-
ned through one positive peak and one negative peak. By the
nature of the rectangle signal each current peak is considered as
a DC level. There is no oset (DC or AC) to the signal. The param-
eters are valid for a load resistance of 1 kOhm.
Name of the
program
Intensity cur-
rent or voltage
(amplitude for
100% setting)
Frequency
1 Phase
Impulse
width high
Impulse
delay/rest
Impulse
width low
Impulse
delay/rest
Pain +/- 600 µA 0.5 Hz 1 s 0 s 1 s 0 s
Pain locally +/- 600 µA 100 Hz 2.5 ms 2.5 ms 2.5 ms 2.5 ms
