Heart Interface 20D User Manual

Part No. 90-0123-00
Libertycombi.p65 11/05/99
28
COMPRESSION / RING TERMINALCOMPRESSION / RING TERMINAL
COMPRESSION / RING TERMINALCOMPRESSION / RING TERMINAL
COMPRESSION / RING TERMINAL
INSTINST
INSTINST
INST
ALLAALLA
ALLAALLA
ALLA
TIONTION
TIONTION
TION
Improper stack up of hardware will cause
excessive heat and fuse failure. Stack up
as shown.
WW
WW
W
ARNINGARNING
ARNINGARNING
ARNING
Battery Cable FusingBattery Cable Fusing
Battery Cable FusingBattery Cable Fusing
Battery Cable Fusing
A fuse is required by the NEC to protect
the battery and cables. A UL Listed DC rated
slow blow fuse must be installed in the positive
(+) battery cable, within 18 inches of the
battery.
Recommended Fuse: Recommended Fuse:
Recommended Fuse: Recommended Fuse:
Recommended Fuse:
UL Listed Class T UL Listed Class T
UL Listed Class T UL Listed Class T
UL Listed Class T
JLLNJLLN
JLLNJLLN
JLLN
with a DC Rating. This fuse with fuse
holder is available from your dealer or Heart
Interface.
RING / RING TERMINALRING / RING TERMINAL
RING / RING TERMINALRING / RING TERMINAL
RING / RING TERMINAL
For Freedom 20 & 20DFor Freedom 20 & 20D
For Freedom 20 & 20DFor Freedom 20 & 20D
For Freedom 20 & 20D
300 Amp Fuse & Holder PN# 84-4156-00 (C/R)*
300 Amp Fuse & Holder PN# 84-41554-00 (R/R)**
300 Amp Fuse Only PN# 84-4117-00
For Freedom 25For Freedom 25
For Freedom 25For Freedom 25
For Freedom 25
300 Amp Fuse & Holder PN# 84-4156-00 (C/R)*
300 Amp Fuse & Holder PN# 84-4154-00 (R/R)**
300 Amp Fuse Only PN# 84-4151-00
For Freedom 30For Freedom 30
For Freedom 30For Freedom 30
For Freedom 30
350 Amp Fuse & Holder PN# 84-4159-00
350 Amp Fuse Only PN# 84-4152-00
* Compression / Ring Terminal
** Ring / Ring Terminal
FUSE HOLDER
FUSE
BATTERY
CABLE
INVERTER
CABLE
FLAT WASHER
LOCK WASHER
NUT
FUSE HOLDER
FUSE
BATTERY
CABLE
INVERTER
CABLE
FLAT WASHER
LOCK WASHER
NUT
+ (red)
EXPLODED VIEW
OF FUSE ASSEMBLY
+
_
For Freedom 10For Freedom 10
For Freedom 10For Freedom 10
For Freedom 10
200 Amp Fuse & Holder PN# 84-4155-00 (C/R)*
200 Amp Fuse & Holder PN# 84-4158-00 (R/R)**
200 Amp Fuse Only PN# 84-4157-00
For Freedom 15 & 15DFor Freedom 15 & 15D
For Freedom 15 & 15DFor Freedom 15 & 15D
For Freedom 15 & 15D
200 Amp Fuse & Holder PN# 84-4155-00 (C/R)*
200 Amp Fuse & Holder PN# 84-4158-00 (R/R)**
200 Amp Fuse Only PN# 84-4157-00
