7
6/21/96
SPECIAL SET UP FOR LINK 2000-R
The following is a list of special set ups that may be necessary to tailor the LINK
2000-R to your system. Please see Pages 10-13 of the LINK 2000 Owners Manual for
details on how to use the FUNC mode.
F10 - ALTERNATOR CURRENT LIMIT
DEFAULT = 100 RANGE = OFF, 30 - 220 AMPS STEP = 10 A
This function is only used with the Link 2000-R (Alternator Regulator Model). It
sets a safety current limit for the alternator. This limits the maximum amount of current that
the alternator can ever deliver. This value is reset to 100Amps in the event of a reset to
factory default values.
CAUTION: OFF defeats this safety feature and the alternator will be ran at
full output until the Acceptance Voltage is reached.
F11 - BATTERY #2 USED FOR CONTROL
DEFAULT ON = BATTERY #2 USED FOR CONTROL
OFF = BATTERY #2 IS NOT USED FOR CONTROL.
This function is used to defeat Battery #2 as a part of the charger control function of
the Link 2000. This is necessary for systems that have both 12V and 24V batteries. Battery
#1 must be the battery that is used by the Freedom inverter (or charged by the alternator
when controlled by the Link 2000R). You may also wish to use this function if the main
house battery is substantially larger than a separate engine battery that is also monitored by
the Link 2000. This will prevent the Link 2000 from making a premature transition to float
based on the smaller engine battery meeting the charged parameters substantially before the
house battery.
NOTE: Function F11 is not changed in a reset to factory default values. If you
wish to change this function you must use the set up routine to change it.
