TABLE OF CONTENTS
One Page Summary of Features Center
Introduction and Special Notes Page 3
Monitor Functions Page 4-5
Inverter and Charger Functions Page 5
Status Line and Starting and Stopping Equalize Page 6
Set Up Page 7
Inverter Set Up Page 8
Monitor Set Up Page 9
Functions Set Up Page 10-14
Data Page 15
How to Use Link 2000 Meters Page 16-17
Ideal Charge Curve Page 18
Synchronizing to a Full Battery (Resetting A hrs to Zero) Page 19-20
Selecting The Charged Parameters Page 21
Selection Rules Page 22
Advanced Functions Page 23
High Discharge Rates and Peukert's Equation Page 24-25
Typical Peukert's Exponents Page 26-27
Error Codes and Trouble shooting Page 28-29
Microprocessor Reset Procedure (Resetting to Factor Defaults) Page 30-31
Summary of Set Up & Historical Values Page 32
Warranty Page 33
Required Reading Prior to Installation Page 34
Wire By Wire Instructions Page 35-36
Wiring Diagrams
SPECIFICATIONS
Supply Voltage 9-40 Volts DC (Not for use with 32V Systems)
Supply Current 28mA (Typical)
Backlight adds 1 to 18mA (Depends on intensity setting)
Voltage Range 8.5-50 Volts DC
Voltage Resolution 0.05 Volts DC
Voltage Accuracy + 0.10 Volts DC at full scale.
Current Range
+ 500 Amps DC
Current Resolution 0.1 Amp DC (From 0 to
+ 42.0 Amps)
1 Amp DC (From
+ 42 to + 500)
Current Accuracy
+ 0.1 Amp DC at full scale low range
+ 1 Amp DC at full scale high range
Current Shunt
+ 0.25% Ratio 50mV @ 500A
Amp Hour Range
+ 9,999 Amp Hours
Amp Hour Accuracy
~ Time of Measurement x Current Error
Time Remaining Range 255 Hours maximum
Charger Voltage Regulation
+ 0.2 Volts DC
Cut out size: 4.75" x 2.75"
Panel size: 5.75" x 3.75"
Weight: Meter 9 oz.; Shunt 20 oz
