HEART HR4136-B1 - Wiring Diagram; Power IN; RS232;RS485 Connections

HR4136-B1
HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART
7
Wiring Diagram:
ANT RS232 RS485
4
5
6
Ground
Pin No. RS232
RXD
TXD
RS485
R- / D-
R+ / D+4
5
Pin No.
 Antenna cable length : 2M with RP-TNC connecter
