HR4136-B1
HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART
12
General specifications:
Characteristic Specification Comment
Supply Voltage Range DC 10 ~ 24V (+/-10%) Supplied from the power terminals
Current consumption @12VDC Average 60mA ; Peak 160mA Approx. 2A max, with rush current
Transmitting Radio Frequency Typical 134.2KHz FSK
Transponder Type TIRIS Tag Single & Multi page Transponder
Operating ambient
temperature
-10 ~ +70°C No freezing
Operating ambient humidity 10 ~ 85%RH No dew condensation
Storage ambient temperature -20 ~ +85°C No freezing
Storage ambient humidity 5 ~ 95%RH No dew condensation
Communication interface RS-232C or RS-485 9600 bps (Default), N.8.1 (fixed)
Weight 450g MAX. No freezing
Dimensions 147 × 110 × 32 mm Except for protrusions on connectors
Mounting system Secured with two M3 screws. Use the enclosed washers.
Communication interface specification:
Characteristic Specification
Connector specification RJ45 connector plug
Communication standard RS-232C or RS-485 only for used HR4135 Gate Controller
Synchronization Asynchronous mode, start-stop synchronization
Communications control standard SEMI/SECS protocol for HR4136-B1 CID Read/Write controller
Baud rate 4800,9600,19200,28800 bps (Default 9600)
Character format (fixed)
Start bit Data bit Parity bit Stop bit Total
1 8 None 1 10
Error control FCS (Frame Check Sequence)
Total cable length
RS-232C 15 m Max.
;
RS-485 : From HR4135 to last one HR4136-B1 Total 1000 m Max.
