Heat & Glo Curve 100S-HS User Manual

2/11/2014     Heat&Glo•7076-108      3
Curve Series
TABLEOFCONTENTS
SafetyAlertKey:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
1 Technical Data .............................................. 4
A.Installation..........................................................................4
B. Safety.................................................................................4
C. Type plates ........................................................................4
2 Installation & Assembly ............................... 5
A.PositioningYourWoodBurningStove...............................5
B.VerticalVenting&CombustionAir.....................................5
C. Horizontal Venting .............................................................5
D. Leveling the Unit ................................................................6
E.PositionNeartoNon-ammableWalls ..............................6
F.DistancetoFurniture:1000mm.........................................6
G.DistancetoFlammableWalls ............................................6
H. Component Pack ...............................................................6
I. Removal of Curve from Pallet .............................................6
3 Dimensions & Clearances ........................... 7
4 Operation ...................................................... 9
A.GeneralUse.......................................................................9
B. Lighting Instructions ...........................................................9
C.YourFirstFire ....................................................................9
D.Fuels....... ...........................................................................9
E.PrimaryAir .........................................................................11
F.UpperAirControl ...............................................................11
G.SecondaryAir ....................................................................11
H.AirwashSystem .................................................................11
I. Side Door Handle Operation ..............................................12
J.FrontDoorSeal ..................................................................12
5 Chimney Systems ........................................ 13
A.ChimneySystems ..............................................................13
B. Drafting ....... .......................................................................13
6 Maintenance ................................................. 14
A.AshDrawer ........................................................................14
B. Refractory ..........................................................................14
C.BafeMaterial....................................................................14
D. Proper Burn .......................................................................14
E. Coated Surfaces ................................................................14
F.CleaningtheGlass.............................................................14
7 Troubleshooting ........................................... 15
8 Warranty ........................................................ 16
9 Service Parts List ......................................... 17
10 Homeowner Notes ...................................... 21

Heat & Glo Curve 100S-HS Specifications

General

Brand	Heat & Glo
Model	Curve 100S-HS
Category	Wood stove
Language	English
