Heatcraft BOHN MAC8X - System Defaults; Control Sensor and Piping

23
Refrigerant
R EF TYP
R-404A R-404A
Box Temperature
BOXTMP
35F -10F
Superheat
SUPRHT
7F 7F
Smart Defrost
SMTDEF
N/A On
Demand Defrost
DMDDFT
N/A Off
Defrost Start Times
DET ST
9am/9pm 3am, 6am, 9am, 12pm, 3pm, 6pm, 9pm, 12pm
Defrost Fail-Safe Times
DEFSAF
40 min. 60 min.
Defrost End Temperature
DEFTMP
45F 55F
Alarm High Temperature
ALR HI
50F 5F
Alarm Low Temperature
ALR LO
30F -15F
Alarm Time
ALRMIN
60 min. 60 min.
Temperature Units
F-C
F F
Clock Setting
12/24 H
12 H 12H
Fan Cycling
FNSTIR
Off Off
Test Mode
TEST
Off Off
Service Mode
SERVIC
Off Off
Beacon II Controller
System Defaults
Figure 11. Control Sensor And Piping
Table 6. System Defaults
