45
*Only the sensor with white leads is shipped as a Service Replacement Part.
Fan Motor 25317701 ALL
Fan Blade 5140C ALL
Fan Guard 37000701 ALL
24752002 LET090BEB2N6MK
Defrost Heater 24752003 LET120BEB2N6MK
24752004 LET160BEB2N6MK
24752004 LET180BEB2N6MK
24752402 LET090BEB2N6MK
Defrost Pan Heater 24752403 LET120BEB2N6MK
24752404 LET160BEB2N6MK
24752404 LET180BEB2N6MK
29326201 ADT070BEB2N6MK
29326201 LET090BEB2N6MK
29326201 ADT052BEB2N6MK
Electric Expansion Valve 29326201 LET120BEB2N6MK
29326201 LET160BEB2N6MK
29326201 ADT104BEB2N6MK
29326201 LET180BEB2N6MK
Expansion Valve Harness 22592101 ALL
Beacon II Control Board 28910103 ALL
Temperature Sensor Kit* 89904902 ALL
Transformer (240/24 - 40 VA) 22529602 ALL
Pressure Transducer 28911201 ALL
Pressure Transducer Harness 22515101 ALL
Parts
Table 7. Condensing Unit Parts List
PART DESCRIPTION PART NUMBER EVAPORATORS
PART DESCRIPTION
CONDENSING UNITS
MAC5X
Compressor - Freezer ZF15K4EZF13K4E ZF15K4E
Compressor - Cooler RST43C1EZS13KAE ZS13KAE
Disconnect Fuses 2251011322510112 22510113
Start Relay - Cooler 1007647 N/A
Start Capacitor - Cooler 7076959 N/A
Run Capacitor - Cooler 7076950 70757856
Compressor Contactor - Cooler 2254304
Compressor Contactor - Freezer 2255845
Condenser Fan Motor 25399101
Condenser Fan Blade 22999901
Fan Guard 23104401
Head Pressure Valve:
Cooler 29317401
Freezer 29317304 29317304
High Pressure Control 28903201
Low Pressure Control - Freezer 2891402
Low Pressure Control - Cooler 2890099
Low Pressure Time Delay 22536801
Crankcase Htr - Freezer 24701301
Fan Cycling Thermostat 2890019
Ambient Temperature Sensor* 88904902
Evaporator Fuses - Freezer 22510002
Evaporator Fuses - Cooler 22510001
Fan Relay (R3, R4 - 240v) 22505201
Fan Relay (R1, R2 - 24v) 22521901
Terminal Block 2251423
MAC7X MAC8X
Table 8. Evaporator Parts List
