4
1
1
1
1
or
Figure 3. Evaporator Placement In Cooler/Freezer
Evaporator Minimum Unit Clearance
1 1/2 H
1 1/2 H
1 1/2 H
Top View
H = Total Height of Unit’s Coil Surface
Side View
1 1/2 H
2 H
H
1/2 W 1/2 W
W
Cooler
Freezer
Loading Door
Note: Whenever possible always try to position the evaporator to blow towards the walk-in door. Never position the
evaporator over or adjacent to a door opening.
Freezer
Cooler
Loading Door
Evaporator Placement
