Heatcraft LFA - LFA Air Defrost Electrical Specs; LFAE Electric Defrost Electrical Specs; LFAH Hot Gas Defrost Electrical Specs

5
5
Model
Shaded Pole Motor PSC Motor EC Motor
115/1 208-230/1 115/1 208-230/1 460/1 115/1 208-230/1
Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts
LFA070 3.6 232 2.4 244 1.64 160 1.0 196 – – 1.8 57 1.0 59
LFA087 3.6 232 2.4 244 1.64 160 1.0 196 – – 1.8 57 1.0 59
LFA120 3.6 232 2.4 244 1.64 160 1.0 196 – – 1.8 57 1.0 59
LFA135 3.6 232 2.4 244 1.64 160 1.0 196 – – 1.8 57 1.0 59
LFA150 3.6 232 2.4 244 1.64 160 1.0 196 – – 1.8 57 1.0 59
LFA170 3.6 232 2.4 244 1.64 160 1.0 196 – – 1.8 57 1.0 59
LFA190 – – – – 2.80 230 1.40 230 0.8 288 5.5 316 2.8 290
LFA230 – – – – 2.80 230 1.40 230 0.8 288 5.5 316 2.8 290
LFA270 – – – – 2.80 230 1.40 230 0.8 288 5.5 316 2.8 290
Model
Shaded Pole Motor PSC Motor EC Motor Defrost Heaters
208-230/1 208-230/1 460/1 208-230/1
Watts
208-230/1 460/1
Amps Watts Amps Watts Amps Watts Amps Watts Total Amps
LFAE070 2.4 244 1.0 196 – – 1.0 59 2,650 11.5 –
LFAE087 2.4 244 1.0 196 – – 1.0 59 2,650 11.5 –
LFAE120 2.4 244 1.0 196 – – 1.0 59 3,850 16.7 –
LFAE135 2.4 244 1.0 196 – – 1.0 59 3,850 16.7 –
LFAE150 2.4 244 1.0 196 – – 1.0 59 3,850 16.7 –
LFAE170 2.4 244 1.0 196 – – 1.0 59 3,850 16.7 –
LFAE190 – – 1.40 230 0.8 288 2.8 290 4,770 20.7 10.4
LFAE230 – – 1.40 230 0.8 288 2.8 290 5,700 24.8 12.4
LFAE270 – – 1.40 230 0.8 288 2.8 290 5,700 24.8 12.4
Model
Shaded Pole Motor PSC Motor EC Motor Drain Pan Heaters
115/1 208-230/1 115/1 208-230/1 460/1 115/1 208-230/1
Watts
115/1
208-
230/1
460/1
Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts Amps Watts Total Amps
LFAH070 3.6 232 2.4 244 1.64 196 1.0 196 – – 1.8 57 1.0 59 660 5.8 2.9 –
LFAH087 3.6 232 2.4 244 1.64 196 1.0 196 – – 1.8 57 1.0 59 660 5.8 2.9 –
LFAH120 3.6 232 2.4 244 1.64 196 1.0 196 – – 1.8 57 1.0 59 960 8.4 4.2 –
LFAH135 3.6 232 2.4 244 1.64 196 1.0 196 – – 1.8 57 1.0 59 960 8.4 4.2 –
LFAH150 3.6 232 2.4 244 1.64 196 1.0 196 – – 1.8 57 1.0 59 960 8.4 4.2 –
LFAH170 3.6 232 2.4 244 1.64 196 1.0 196 – – 1.8 57 1.0 59 960 8.4 4.2 –
LFAH190 – – – – 2.80 230 1.4 230 .08 288 5.5 316 2.8 290 1,190 10.4 5.2 2.6
LFAH230 – – – – 2.80 230 1.4 230 .08 288 5.5 316 2.8 290 1,426 12.4 6.2 3.1
LFAH270 – – – – 2.80 230 1.4 230 .08 288 5.5 316 2.8 290 1,426 12.4 6.2 3.1
PERFORMANCE DATA
Model LFA Air Defrost
Model LFAE Electric Defrost
Model LFAH Hot Gas Defrost
