Heatrae Sadia Multipoint 30 User Manual

4
FIGURE 01: DIMENSIONS
2.0 TECHNICAL SPECIFICATIONS
Electrical Rating 3.0kW @ 240V/ 2.75kW @ 230V
Capacity 30 and 50 litres
Weight (50 Litre) 69.3kg (full)
Weight (30 Litre) 42.5kg (full)
Operating pressure 0.35 MPa (3.5 bar)
Rated pressure 0.6 MPa (6.0 bar)
Expansion vessel charge pressure 0.35 MPa (3.5 bar)
Expansion relief valve setting 0.6 MPa (6.0 bar)
Minimum supply pressure 0.08 MPa (0.8 bar)
Maximum supply pressure to PRV 1.6 MPa (16.0 bar)
Temperature / Pressure Relief Valve 90°C / 0.7 MPa (7.0 bar)
50 Litre
30 Litre
Dim ension
888
616
A
937
665
B
1060
788
C
778
506
D

Heatrae Sadia Multipoint 30 Specifications
