WARNING! B
The plug of the machine (apparatus) must be unplugged from the mains supply before
any intervention, assembly, service, adjustment, etc. This will eliminate the possibility of
electric shock and accidental start-up of the active parts of the machine.
THIS WARNING IS NOT REPEATED IN ANY FOLLOWING POINTS!
Note: I
Don‘t plug the power cord in before or during installation!
LOCATION
• The pump must be set-up steadily on a horizontal, level surface, sufficiently resistant to
the pump’s weight with the pressure vessel filled.
• To prevent vibration and ensure stability, the pump should be placed on a cushioned base
and secured by screwing the feet to the floor.
• When operating in open water areas (e.g. garden ponds), the pump must be placed on
a level, stable surface so that it doesn‘t flood and prevent it from falling.
• To pump water that may contain mechanical particles, solutes, animals, algae and the like,
it‘s necessary to use a filter on the suction part of the pump.
• The pump workstation should be well ventilated and protected from the weather, where
the temperature never drops below +3°C
C The pump and the pressure vessel must never freeze! If the water in the pressure
vessel freezes, the bellows will be damaged (cut) by ice. This could damage the pump
body or mechanical seal.
INSTALLATION
NEVER start the pump dry without the suction or pressure piping connected.
Note: I
The piping must be sufficiently strong and resistant to negative pressure (metal, PE
or PPR pipes, reinforced PVC hoses, etc.) with the smallest possible length according to
the conditions and location.
• Always use suitable sealing material (tape, tow, gasket) when connecting fittings
SUCTION PIPE
Note: I
A suction basket with a return valve must be installed at the end of the suction
section for the waterwork to function properly. Unnecessary increase of suction height and
length of suction piping or its small diameter increases load of water pump.
- A suction basket with a return valve must be installed at the end of the suction section
for the pump to function properly.
- Mount the suction basket with a flap on the suction line and immerse the suction
basket in the pumped water.
- Mount 1” flange to the other end of the pipe
- Water the suction line and connect the suction hose to the pump
PRESSURE PIPING
Note: I
Fixed/permanent pressure pipes should be installed professionally, not by yourself.
- Mount the 1“ flange on the pressure hose/pipe and connect it to the pump
