3-11
&KDSWHU$'9$1&('23(5$7,21
5
Fold a piece of paper as desired and
measure the dimensions of the A, B
and C.
The folding sizes should be within the
following ranges.
$WRPP
IROGHGVL]HIRUWKH¿UVWIROGLQJSODWH
%WRPP
IROGHGVL]HIRUWKHVHFRQGIROGLQJSODWH
&PPRUVKRUWHU
IROGHGSDSHUOHQJWK
The position of A and B
Single fold Double fold Irregular
accordion fold
Letter fold Accordion fold Gate fold
Paper feed direction
Paper ejection direction
A (B=0mm)
B
A
B
A
B
B
B
A
A
A
Rough adjustment knob
6
Adjust the rough adjustment knob
RIWKH¿UVWIROGLQJSODWHWRWKHPDUN
corresponding to measurement A.
7
Adjust the rough adjustment knob
RIWKH¿UVWIROGLQJSODWHWRWKHPDUN
corresponding to measurement B.
Ɣ The rough adjustment knob cannot
be turned either clockwise or
counterclockwise. Make sure that you
pull up the knob when you want to
move it.
Ɣ After moving the rough adjustment
NQREWXUQWKH¿QHDGMXVWPHQWNQRE
to the right and left a few times to
check that it moves slightly.
Accordion fold (example)
