3-29
&KDSWHU$'9$1&('23(5$7,21
5-2. Correcting Folding Misalignment along Sides of Paper
Paper feeding
direction
:KHQIROGHGSDSHULVPLVDOLJQHGDORQJWKHVLGHV
RISDSHUDVVKRZQLQWKH¿JXUHWXUQWKHVODQWFRUUHFWLRQ
knob to correct the misalignment.
<RXPD\QHHG¿QHDGMXVWPHQWVDFFRUGLQJWRYDULRXVFRQGLWLRQVVXFKDVHQYLURQPHQWDO
FRQGLWLRQVWHPSHUDWXUHKXPLGLW\SDSHUTXDOLW\SDSHUWKLFNQHVVSDSHU¿EHU
direction, cutting accuracy and printing conditions.
Slant correction knob
1
Turn the slant correction knob to
adjust the folding slippage.
Slant correction knob
If folding slippage is as shown in Figure A,
turn the knob in the direction of the arrow.
Slant correction knob
If folding slippage is as shown in Figure B,
turn the knob in the direction of the arrow.
Pin
Round hole
Slant correction knob
2
$IWHU¿QLVKLQJRSHUDWLRQVEHVXUH
to turn the slant correction knob to
align the round holes of the paper
feed table with the pin.
The position at which the round hole meets
the pin is the standard position.
