5-4
&KDSWHU&/($1,1*7+(81,7
1-3. Cleaning the Paper Separator
Top cover
1
Open the top cover.
Paper separator
Cloth
Paper feed ring
(middle)
2
Insert a cloth moistened with alcohol
between the paper feed ring (middle)
and the paper separator.
3
Turn the paper feed rings in the
direction of the arrow.
1-4. Cleaning the Paper Sensor
Paper sensor
Clean the paper sensor using an air
duster or a cotton bud.
To Next Page
