Hefter TF MEGA-A - Cleaning the Paper Separator

5-3
Chapter5 Cleaning the Unit
Paper feed ring
2
Rotate the rubber roll, and clean o
the dirt with a cloth moistened with
alcohol.
1-3. Cleaning the Paper Separator
Top cover
1
Open the top cover.
Paper separator
Cloth
Paper feed ring
(middle)
2
Insert a cloth moistened with alcohol
between the paper feed ring (middle)
and the paper separator.
3
Turn the paper feed rings in the
direction of the arrow.
