HEIDENHAIN QUADRA-CHEK 2000 User Manual

Settings | Axes
15.7.5
Squareness error compensation (SEC)
Path:
Settings ► Axes ► General settings ► Error compensation ►
Squareness error compensation (SEC)
Parameter Explanation
XY plane
XZ Plane
YZ plane
Mechanical influences on the squareness of the axes relative to
each other are compensated
Setting range: 85° ... 95°
Default value: 90
15.7.6
Axes X, Y ...
Path:
Settings ► Axes ► X, Y ...
Parameters Explanation
Axis name
Selection of the axis name displayed in the position preview
Encoder
Configuration of the connected encoder
Further information: "Encoder", Page 377
Error compensation Configuration of the linear error compensation LEC or segment-
ed linear error compensation SLEC
Further information: "Linear error compensation (LEC)",
Page 383
Further information: "Segmented linear error compensation
(SLEC)", Page 383
Error compensation is only available if you have
configured a Linear encoder under Encoder model.
If an Angle encoder or Angle encoder as linear
encoder has been configured, error compensation is
disabled automatically.
15
HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
375

HEIDENHAIN QUADRA-CHEK 2000 Specifications

General

Resolution	0.1 µm
Input Voltage	100-240 V AC
Display	Color touchscreen
Measurement Range	200 mm
Interfaces	USB, Ethernet
Power Supply	50 to 60 Hz
Weight	6 kg
