1 Stipulated usage
1.1 Component list
Designation of individual parts
Diag. 1
Pos Description Total
1 Handle 1x
2 Rating plate 1x
3 Cover EVO 1x
4 Sponge rubber 20 / 20 1x
5 LS-screw Phillips M6 x 30 4x
6 LS-screw Phillips M6 x 25 3x
7 Reinforcement plate EVO 240V 1x
7 Reinforcement plate EVO 120V 1x
8 LS-screw Phillips M6 x 20 4x
11 Control unit ONE/EVO 240V 1x
11 Control unit ONE/EVO 120V 1x
12 Capacitor 8µF 240V 1x
12 Capacitor 25µF 120V 1x
13 Capacitor 25µF 240V 1x
13 Capacitor 60µF 120V 1x
14 Countersunk screw Torx M4 x 20 1x
15 Washer for countersunk screw M4 1x
16 Pulley, aluminium 240V 1x
16 Pulley, aluminium 120V 1x
17 Snap-on belt 1x
18 Hexagonal nut M12 x 1 / 0.5D 1x
19 Washer 13 / 24 x 2.5 1x
20 Pulley, plastic 240V 1x
20 Pulley, plastic 120V 1x
21 Drive housing EVO 1x
22 Speed control sensor EVO 1x
23 LS-screw Torx M5 x 16 4x
24 Motor EVO 240V / 300W 1x
24 Motor EVO 120V / 300W 1x
Pos Description Total
25 Gear shaft 1x
26 Radial ball bearing 6001-2Z 2x
27 Spacer sleeve 1x
28 Retaining ring for bores Ø28 1x
29 Spring key 4 x 4 x 16 1x
31 LS-screw Phillips M6 x 12 8x
32 Switch support x
33 Washer 12 / 18 x 1 1x
34 Lever for switch 1x
35 Spring for switch 1x
37 Retaining ring for shaft size 9 1x
38 Micro switch 1x
39 Socket head cap screw
Phillips M3 x 20 2x
40 Hexagonal nut self-securing M3 2x
41 Ring spanner Ø30 x
42 Cord Ø9 x 2000 1x
43 Hexagonal nut M20 x 1.5 1x
44 Anti-kink sleeve M20 x 1.5 1x
45 Cable with Schuko plug 1x
45 Cable with USA plug 1x
45 Cable with AUS plug 1x
46 PT-screw Torx KA40 x 16 8x
47 Motor housing EVO 1x
48 Base EVO 1x
50 Micro-fuse 5A / 120V 1x
52 Catch spring ONE/EVO 1x
53 PH-screw M4 x 10 1x
Converter Schuko/GB plug 5A 1x
