4. Connecting the cable
Indoor unit
Connect the power cord to the indoor unit by connecting the wires to the terminals on
the control board individually in accordance with the outdoor unit connection.
Note: for some models, it is necessary to remove the cabinet to connect to the indoor
unit terminal.
Outdoor unit
e. Remove the access door from the unit by loosening the screw. Connect the
wires to the terminals on the control board individually as follows.
f. Secure the power cord onto the control board with cable clamp.
g. Reinstall the access door to the original position with the screw.
h. Use a recognized circuit breaker for 24K model between the power source and
the unit. A disconnecting device to adequately disconnect all supply lines must
be fitted.
