COMPONENTS & SETUP CHAPTER 3
3 Components and Setup
3.1 Basic System Components
The basic system consists of the following components:
a ) PAM-2500 Control Unit
b ) Special Fiberoptics 2010-F
c ) Distance Clip 60° 2010-A
d ) Battery Charger MINI-PAM/L
e ) MINI-PAM/AK cable
f ) Special USB cable PAM-2500/K1
g ) Fluorescence Standard Foil
h ) Spare Fuse
i ) Carrier Bag
j ) Transport Box 2040-T
k ) Software. PamWin-3 System Control and Data Acquisition
3.2 Basic System Setup
Note: Great caution should be exercised to prevent any dirt or for-
eign matter from entering the ports for the fiberoptics pins.
To set up the PAM-2500 fluorometer:
- Connect fiberoptics to the control unit using the three-pin op-
tical connector at the front of the unit (Fig. 3.1).
11
