7 Electrical Connection
Digital Positioning System 2000 19
If there is no battery provided, it is absolutely necessary that a three phase power supply
or a stabilized single phase power supply with at least 24 V DC, 10 Amps output power be
used as a power source.
The cable sizes and cable lengths described in the wiring diagrams must
not be exceeded!y
When power supply, battery and cabling have been correctly dimensioned, then on starting
the engine or with the positioner operating at maximum current consumption (approx.
6.4 A), a drop of the supply voltage directly at the control unit of approx. 2 Volts
maximum only will be admissible.
