5 FSZ Basis – technical data
5 FSZ Basis – technical data
Nominal voltage 230 V AC
Nominal current consumption 0.08 A eff.
Rated frequency 50/60 Hz
Power consumption 13.8 VA
Nominal output voltage 24 V DC
Residual ripple 200 mV
SS
Output current max. 400 mA
Output power 9.6 W
Relay
Switching voltage AC
Switching current AC
Switching voltage DC
Switching current at 30 V DC
Switching current at 24 V DC
1 alternating contact, potential-free
max. 250 V AC
max. 5 A AC
max. 30 V DC
max. 3 A DC
max. 5 A DC
Operating ambient temperature -10 °C to +50 °C
Storage temperature -10 °C to +60 °C
Ambient conditions humidity
(continuous, without condensation) ≤ 34 °C
10 ... 95 % RH
Ambient conditions humidity
(continuous, without condensation) > 34 °C
max. 35 g/m³
min. 10 % RH
Degree of protection with exposed assembly IP 65
Degree of protection with cable entry from behind IP 30
Safety class "I"
Housing PC-ABS housing
Colour signal white according to RAL 9003
Installation exposed assembly
Installation position as desired
