9
Dimensions and weight of main dismountable parts
model
item
Unit
CPD15SQ
CPD16SQ
CPD18SQ
CPD20SQ
GB2Li
Counterweight
Max. overall size
mm
410×1060×775
425×1060×775
455×1060×775
Weight
kg
750
945
1068
Assistant
counterweight
Max. overall size
mm
980×190×522
980×190×522
980×190×630
980×190×630
Weight
kg
471
658
516
791
Overhead guard
Max. overall size
mm
1238×1030×1541
1292×1030×1541
1400×1030×1541
Weight
kg
65
75
90
Mast（lifting
height 3300mm）
Max. overall size
mm
1267×1010×2075
1267×1086×2075
Weight
kg
577
604
