Magic 600 N000924 12/2010 13 / 208
Changing the fuse
Pull out mains plug.
• Remove the operator hood, see page 164.
• Remove the faulty fuse (S1) from the fuse holder (S2) and
replace it. Make sure that the new fuse has the correct
value!
• Replace the operator hood.
Restore the mains connection.
Changing the battery of the remote
transmitter
Open the housing cover. Remove the battery, fit a new one
and replace the housing cover.
Use only leak-proof batteries. Make sure the polarity
is correct. Dispose of used batteries in an
environmentally-friendly way.
Monthly
• Load switch-off (entrapment protection device)
• Emergency lock release
• Additional safety devices (if fitted)
Every 6 months
• Mounting of door operator on the ceiling and on the wall
See page 167.
Declaration of incorporation see page 168.
1) The transmission range of the remote transmitter may be
reduced considerably by external interference.
2) Dimensions with turned operator head
3) plus stroke length
See pages 162 and 163.
Available from specialised dealer's:
• 4-command multi-use remote transmitter
• Wall keypad
• Key-operated control
• Keypad
• Wireless keypad
• External antenna
• Photo cell
• Extension module for opto-sensor
• Extension module for warning light
• Emergency lock release from outside or inside
• Safety rail 8.2 kohms
• Potential-free receiver, various frequencies
Removing the door operator takes place in the
reverse sequence of the installation instructions
and must be carried out by qualified technicians.
Dispose of the device according to environmental
guidelines. Electrical parts must not be disposed of
as domestic waste. 2002/96/EG (WEEE)
Operator closes the
door slowly (soft
start) whilst door
operator light flashes
Operator teaches in the travel
automatically. After CLOSED end
position, moves automatically to
OPEN end position. If the door
operator light flashes in intervals of
4, carry outTeaching in the door
operator (Chapter 15)
The operator
switches off during
motion.
Check that the door is running
smoothly and that the entrapment
protection device is working properly
/ Reset / Teach in the door operator
Remote transmitter is
not working, LED not
alight
Replace the batteries
Remote transmitter is
not working
If the function message assigned to
the transmission pulse is not
displayed whilst the transmitter is
actuated (see Chapter 16): Teach in
remote transmitter / Poor reception
(install optional antenna) energy-
saving lamps
The operator cannot
be used via the wall
keypad (optional).
Check the wall keypad and control
wire.
The operator cannot
be used via the
remote transmitter
(optional).
Radio level too weak. There are
interfering radio signals from other
transmission sources / Carry out
radio level check as described below
23 Maintenance intervals
24 Declaration of conformity
25 Technical data
Mains connection 230 V~, 50/60 Hz
Device fuse 1.6 A, T (slow-blow)
Power consumption at rated load 140 W
Closed current < 2 W
Degree of protection For dry rooms
only, IP 20
Protection class 1
Wireless remote control 433.92 MHz AM
Remote transmitter range 1) 15 - 50 m
Remote transmitter batteries CR 2032 (3 V)
Idle speed ~ OPEN >210 mm/s
~ CLOSE >140 mm/s
Traction 600 N
Rated load 150 N
Stroke length
Magic 600 2890 +/- 25 mm
Magic 600 long 3978 +/- 25 mm
Total length 3) 615 +/- 25 mm
Total length 2) 3) 485 +/- 25 mm
Width 285 mm
Width 2) 363 mm
Installation height drive rail 40 mm
Permissible
ambient temperatures
-20°C to 50 °C
Storage -20°C to 80 °C
Lighting E14, max. 40 W
Maximum number of duty cycles
per hour at rated load
20
Maximum number of duty cycles
without a break at rated load
8
Noise level at a distance of 2 m ≤69 dB(A)
26 Replacement parts
27 Accessories (optional)
28 Removal, Disposal
