PRIMAAX
®
EX / PRIMAAX
®
for Volvo Vehicles
Special Tools 10 17730-254
QUIK-ALIGN SOCKET TOOL
Hendrickson PRIMAAXEX QUIK-ALIGN Socket Tool is available from the Owatonna Tool Corporation (Owatonna Tool No. 1767,
website: www.otctools.com) or a shop made tool can be made from the drawing shown. Hendrickson does not supply QUIK-ALIGN
tooling. Material: Optional per customer discretion, Grade 80 or better case harden per SAE requirements.
TORQUE ROD BUSHING
This shop made tool is designed for the torque rod bushing. Bushing tools
are made from cold rolled steel or equivalent. Drawing is for reference only,
Hendrickson does not supply this tool.
TORQUE ROD
Bushing Receiver
5.00
2.00"
2.50"
