17730-254 13 Parts Lists
KEY NO. PART NO. DESCRIPTION NO.REQ. KEY NO. PART NO. DESCRIPTION NO.REQ.
PRIMAAX
®
EX for Volvo Vehicles
1 67222-000 Frame Hanger 4
60632-021 QUIK-ALIGN Collar Service Kit, Axle Set,
Includes Key Nos. 2-6
60632-020 QUIK-ALIGN Pivot Bushing Service Kit,
One Axle, Includes Key Nos. 2-6, 17
60632-019 QUIK-ALIGN Collar Service Kit,
Per Wheel End, Includes Key Nos. 2-6
60632-018 QUIK-ALIGN Fasteners Service Kit,
Per Wheel End, Includes Key Nos. 4-6
2 64633-000 QUIK-ALIGN Concentric Collar 4
3 64632-000 QUIK-ALIGN Eccentric Collar 4
4 68217-000 1.0"-14 UNF-2A H-Coat 7.5" Hex Bolt 4
5 68232-000 1.0" H-Coat Flat Washer 8
6 68218-000 1.0"-14 UNF-2B H-Coat Locknut 4
7 Top Pad 4
a 60877-001 8.5" Ride Height
b 65641-000 10" Ride Height
8 65139-003 Axle Spacer, 8.5" Ride Height (if equipped) 4
U-bolt Service Kit, One Wheel End,
48718-125 8.5" Ride Height, Includes Key Nos. 9a,10-11
48718-126 10" Ride Height, Includes Key Nos. 9b,10-11
9 U-bolt 8
a 59367-004 ¾" Square 10.375"
b 59367-009 ¾" Square 10.0"
10 22962-001 ¾" Flat Washer 16
11 49685-000 ¾"-16 UNF U-bolt Locknut 16
12 60556-XXX Bottom Cap, See pinion angle chart below 4
34013-107 D-Pin Service Kit, One Wheel End,
Includes Key Nos. 13-15, 18
13 21867-036 ¾"-16 UNF 5.0" Bolt 8
14 22962-001 ¾" Flat Washer 16
15 30191-000 ¾"-16 UNF Locknut 8
16 ***U-beam Assembly, See chart below
Includes Key Nos. 17-18
67249-003 Rear 1
67249-004 Front 1
17 58648-000 QUIK-ALIGN Pivot Bushing 4
18 60383-000 D-Pin Bushing 4
60961-230 Air Spring Assembly Service Kit,
One Wheel End, Includes Key Nos. 19-22
19 67043-002 Air Spring Assembly 4
20 60911-002 Lower Air Spring Mounting Bracket 4
21 17700-010 ½"-13 UNC Locknut 8
22 22962-014 ½" Flat Washer 8
23 67274-XXX Longitudinal Torque Rod Assembly, See pinion 4
angle chart below, Replaces 64981-XXX
58821-012 Longitudinal Torque Rod Rear Bolt
Service Kit, One Side Only,
Includes Key Nos. 24-26
24 30418-009
7
⁄8"-14 UNF-2A 5.5" Hex Bolt 4
25 22962-034
7
⁄8" Flat Washer 8
26 29248-000
7
⁄8"-14 UNF-2B Locknut 4
27 **M16 x 2 6G Bolt 8
28 **M16 Washer 16
29 **M16 x 2 6H Locknut 8
30 **Shim (may or may not required) As req.
31 **Transverse Rod Assembly 2
60961-106 Shock Absorber Service Kit, One Wheel End,
Includes Key Nos. 32, 34-39
32 60657-007 Shock Absorber 4
33 67463-006 Shock Upper Frame Bracket 4
34 50764-010 ¾"-10 UNC 4.25" Upper Shock Bolt 4
35 22962-001 ¾" Flat Washer 4
36 49842-000 ¾"-10 UNC Locknut 4
37 32043-017
5
⁄8"-11 UNC 6.0" Lower Shock Bolt 4
38 22962-004
5
⁄8" Flat Washer 8
39 47764-000
5
⁄8"-11 UNC-2B Locknut 4
Not Shown **Height Control Valve Assembly 1
Not Shown **Height Control Valve Linkage 1
NOTE: * Quantities shown are for a tandem con guration.
** Item Required, component supplied by vehicle manufacturer. Hendrickson is not responsible for components not supplied by Hendrickson, for
assistance with maintenance and rebuild instructions on these components see vehicle manufacturer.
***U-beam Assembly Enhancement
AFTERMARKET SERVICE KIT
NO. 69565-001, AXLE SET
CONTENTS
PART NO. DESCRIPTION QTY.
69351-000
Sika ex 221 Polyurethane
Sealant, 300 ml Tube
1
69432-000 Tamper Resistant Cap 2
69570-000 Loctite
®
277 - 10 ml Bottle 1
50104-006
7
⁄8"-9 UNC 4.0" Hex Bolt 2
22962-042
7
⁄8" H-Coat Flat Washer 2
*** In the event any service to the suspension
requiring disassembly of a U-beam
assembly equipped with integrated end
caps, the Loctite 277, tamper resistant caps
and Sika ex 221 polyurethane sealant
must be properly installed to ensure
components function to their highest
ef ciency. The enhancement components
can be purchased individually or as an
aftermarket service kit.
Pinion Angle Chart
8.5'' RIDE HEIGHT 10'' RIDE HEIGHT
Pinion
Angle
(degree)
Bottom Cap
Part No.
Longitudinal Torque Rod
Pinion
Angle
(degree)
Bottom Cap
Part No.
Longitudinal Torque Rod
Length
(mm)
Part No
Length
(mm)
Part No
2.9 60556-025
530 (front) 67274-530
2.9 60556-025
530 (front) 67274-530
6 60556-060 6.1 60556-060
7.9 60556-120 550 (front) 67274-550 8.2 60556-120 550 (front) 67274-550
10.3 60556-100
575 (rear) 67274-575
9.8 60556-100
570 (rear) 67274-570
10.7 60556-105 10.2 60556-105
11.2 60556-110 10.7 60556-110
11.6 60556-115 11.2 60556-115
12.1 60556-120 11.6 60556-120
13 60556-130 12.6 60556-130
13.4 60556-135 13.1 60556-135
Measured with Pinion QUIK-ALIGN at neutral position (12 O'Clock)
