17730-254 15 Parts Lists
KEY NO. PART NO. DESCRIPTION NO.REQ. KEY NO. PART NO. DESCRIPTION NO.REQ.
PRIMAAX
®
for Volvo Vehicles
1 65702-001 Frame Hanger 4
60632-021 QUIK-ALIGN Collar Service Kit, Axle Set,
Includes Key Nos. 2-6
60632-020 QUIK-ALIGN Pivot Bushing Service Kit,
One Axle, Includes Key Nos. 2-6, 18
60632-019 QUIK-ALIGN Collar Service Kit,
Per Wheel End, Includes Key Nos. 2-6
60632-018 QUIK-ALIGN Fasteners Service Kit,
Per Wheel End, Includes Key Nos. 4-6
2 64633-000 QUIK-ALIGN Concentric Collar 4
3 64632-000 QUIK-ALIGN Eccentric Collar 4
4 68217-000 1.0"-14 UNF-2A H-Coat 7.5" Hex Bolt 4
Replaces 64107-000
5 68232-000 1.0" H-Coat Flat Washer 8
Replaces 22962-035
6 68218-000 1.0"-14 UNF-2B H-Coat Locknut 4
Replaces 64108-000
7 Top Pad 4
a 60877-001 8.5" Ride Height
b 65641-000 10" Ride Height
8 65139-003 Axle Spacer, 8.5" Ride Height (if equipped) 4
U-bolt Service Kit, One Wheel End,
48718-125 8.5" Ride Height, Includes Key Nos. 9a,10-11
48718-126 10" Ride Height, Includes Key Nos. 9b,10-11
9 U-bolt 8
a 59367-004 ¾" Square 10.375"
b 59367-009 ¾" Square 10.0"
10 22962-001 ¾" Flat Washer 16
11 49685-000 ¾"-16 UNF U-bolt Locknut 16
12 60556-XXX Bottom Cap, See pinion angle chart on page 3 4
34013-107 D-Pin Service Kit, One Wheel End,
Includes Key Nos. 13-15, 19
13 21867-036 ¾"-16 UNF 5.0" Bolt 8
14 22962-001 ¾" Flat Washer 16
15 30191-000 ¾"-16 UNF Locknut 8
16 ***Support Beam Assembly (60831-XXX, see
replacement guide below)
17 ***Cross Tube (60912-001, see replacement
guide below)
18 58648-000 QUIK-ALIGN Pivot Bushing 4
19 60383-000 D-Pin Bushing 4
60961-062 Air Spring Assembly Service Kit,
One Wheel End, Includes Key Nos. 20-23
20 60271-002 Air Spring Assembly 4
21 60911-000 Lower Air Spring Mounting Bracket 4
22 17700-010 ½"-13 UNC Locknut 8
23 22962-014 ½" Flat Washer 8
24 60822-000 End Cap 4
25 50104-003
7
⁄8"-9 UNC 3.5" Hex Bolt 4
26 22962-034
7
⁄8" Dacromet Flat Washer 4
27 67274-XXX Longitudinal Torque Rod Assembly, See pinion 4
angle chart on page 3, Replaces 64981-XXX
58821-012 Longitudinal Torque Rod Rear Bolt
Service Kit, One Wheel End,
Includes Key Nos. 28-30
28 30418-009
7
⁄8"-14 UNF-2A 5.50" Hex Bolt 4
29 22962-034
7
⁄8" Dacromet Flat Washer 8
30 29248-000
7
⁄8"-14 UNF-2B Locknut 4
31 **M16 x 2 6G Bolt 8
32 **M16 Washer 16
33 **M16 x 2 6H Locknut 8
34 **Shim (may or may not be required) As Req
35 **Transverse Rod Assembly 2
60961-106 Shock Absorber Service Kit, One Wheel End,
Includes Key Nos. 36, 38-43
36 60657-007 Shock Absorber 4
37 67463-006 Shock Upper Frame Bracket 4
Replaces 65000-006
38 50764-010 ¾"-10 UNC 4.25" Upper Shock Bolt 4
39 22962-001 ¾" Flat Washer 4
40 49842-000 ¾"-10 UNC Locknut 4
41 32043-017
5
⁄8"-11 UNC 6.0" Lower Shock Bolt 4
42 22962-004
5
⁄8" Flat Washer 8
43 47764-000
5
⁄8"-11 UNC-2B Locknut 4
Not Shown **Height Control Valve Assembly 1
Not Shown **Height Control Valve Linkage 1
NOTE: * Quantities shown are for a tandem con guration.
** Item Required, component supplied by Vehicle Manufacturer. Hendrickson is not responsible for components not supplied by Hendrickson, for
assistance with maintenance and rebuild instructions on these components see vehicle manufacturer.
*** No longer available for service, see replacement guide below. For more information, refer to Hendrickson Technical Bulletin SEU-0229 or contact
Hendrickson Tech Services.
SUPPORT BEAM AND CROSS TUBE ASSEMBLY REPLACEMENT GUIDE
Key No. Description Current Part No. Replacement Kit No. Comments
16 Support Beam Assembly
60831-003 (LHF)
60831-004 (RHF)
60961-237 (Forward)
Requires the replacement of associated sus-
pension parts on one axle.
Replacement Kit includes two new support
beam assemblies, one cross tube, two air
spring assemblies, air spring fasteners,
QUIK-ALIGN fasteners and D-pin fasteners.
60831-001 (LHR)
60831-002 (RHR)
60961-238 (Rear)
17 Cross Tube 60912-001
60961-237 (Forward)
60961-238 (Rear)
