6.2 Adjusting the seat height
In order for your Aurora to deliver maximum comfort, it is necessary to adjust the
seat height to suit your needs. is is done as follows:
NB! Make sure the swing wire do not get too tight, but glide freely. Also make sure
that the fabric strip from the foot pad is moved forward on the seat plate so that
it is not too tight! Do not adjust higher/lower then the attached guide suggests!
• Lift the chai r about halfway up using the handcontroller. en remove the
seatplate by removing the wing nuts below the screws towards the back of
the plate.
• Loosen the screws so that the actuator bracket moves freely A.
• Loosen the column by opening the screws B.
• Adjust the chair to the correct height by turning screw C.
• Fasten screws A and B, and reattach the seat plate.
B
C
A
ENGLISH
