Service Instructions HERAsafe HS/12/18
Valid: 05.2001 / 50060091 / A • 17 •
4.1 List of the defined spare parts, mechanical components
Position Description Order no. Service instructions
Auxiliary devices
1 Joint sealant, Sista F 109, Henkel Co. 50044214
2 Leak detector, Güpo, Art. 301 50060128
Mechanical components
3 Drain valve MS ½” 50046618 Section 4.9
4
Prefilter panel, HS 12 50057962
Section 4.5
5
Prefilter panel, HS 18 50058009
Section 4.5
6
Support stand, HS 12
50057596
Section 4.8
7
Support stand, HS 18 50057597
Section 4.8
8
Support stand installation kit
50058185 Section 4.8
9
Sealing ring 5005 8489
Section 4.8
10
Side window 7,46 x 610 x 460 50043699
Section 4.10
11 Connection plate with 3 holes 50046978 Section 4.10
12
Twist stopper 50046334
Section 4.11
13 Flat seal
50058489
Section 4.11
14 Nut 03710384 Section 4.11
15 Rubber grommet 03651539 Section 4.11
16
Perforated plate, HS 12 50050699
Section 4.6
17
Perforated plate, HS 18 50052062
Section 4.6
18
Exhaust filter, HS 12 (18 in x 24 in x 4,6 in) 50059628
Section 4.14
19
Exhaust filter, HS 18 (24 in x 24 in x 4,6 in)
50059630 Section 4.14
20 Distance tube 50045946 Section 4.14
21
Blower 50059898
Section 4.16
22
Downflow filter, HS 12 (48 in x 24 in x 2,7 in) 50059627
Section 4.15
23
Downflow filter, HS 18 (72 in x 24 in x 2,7 in) 50059629
Section 4.15
24
One-way diaphragm filter 50045320
Section 4.17
25
Cover plate, HS 12 50046942
Section 4.3
26
Cover plate, HS 18 50046944
Section 4.3
27 Front window, HS 12 50059903 Section 4.12
28 Front window, HS 18 50060349 Section 4.12
29 Screw shackle with rope for front window 50044205 Section 4.12
30 Spring 50057784 Section 4.12
31
Tube drive HS 12 50059899
Section 4.13
32
Tube drive HS 18 50061594
Section 4.13
33
Hood bracket 50059900
Section 4.3
34 Screw joint 50043537
35
Cap for screw joint 50043591
36
Pressure gauge 50047066
37 T-connector for tube 50044386
38 Tube 03667303
39
Plenum sack, HS 12 50043527
