Hercules DJ Console 4-Mx Quick Start Guide

Microphone level (MIC)
- When selecting the microphone as Input or recording source, keep in mind
that it will not be possible to use Input 1-2 at the same time.
- It is not necessary to select MIC if you simply whish to use the Talk Over
mode (Mic On-Off) since this function acts directly on the hardware of 4-Mx
by sending the signal of the microphone input to the main output.
We recommend using dynamic microphones with an impedance rating of 1
to 64 ohms. If you wish to use a condenser microphone, please note that
an external power source will be required as the Console doesn’t provide
phantom power (+48 V).
Phono Level
Used for:
- Turntables with a Phono level signal.
If necessary, connect the ground between the DJ Console your the turntable.
Note that this setting should not be used if your turntable produces a Line
Level output (Consult the user manual for more details). The same applies if
you are using a Phono/Line level converter.
Line level
Used for:
- Consumer CD players
- MP3 players.
- Musical instruments (keyboard, Effects)
- Turntables with a Line level signal.
- Phono/Line level converter

Hercules DJ Console 4-Mx Specifications

General

Channels quantity	- channels
Digital sound processing	- bit
Booth out (1/4\")	1
Line inputs (RCA)	2
Minimum RAM	1024 MB
Minimum processor	1.5GHz
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
