4
# DJCONTROL INPULSE 500
CONTROL
FUNCTION SHIFT FUNCTION
19 BEATMATCH GUIDE Toggle BEAT ALIGN & TEMPO MATCH features on / o -
20 CHANNEL FADER Adjust channel volume Fader start
21 FILTER FX SECTION Apply low pass or high pass lter per deck, toggle FX
SEE FX SECTION FOR MORE INFORMATION
-
22 AUX SECTION Adjust AUX volume / Adjust AUX high pass & low pass lter -
23 PERFORMANCE PADS SEE PERFORMANCE PADS SECTION FOR MORE INFORMATION -
24 CUE Set Temp Cue point / Cue from set Temp Cue point Load previous track to deck
25 SHIFT Use in conjunction with other controls as modier -
26 OUT Set Loop Out point / Edit Loop Out point Parameter right
27 IN Set Loop In point / Edit Loop In point. Press and hold to toggle 4 beat
autoloop
Parameter left
28 AUTOLOOP Press in to toggle autoloop, turn left to halve loop length, turn right to
double loop length
-
29 JOG WHEEL Control waveform within Serato DJ Pro in vinyl mode, or pitch bend with
vinyl mode o
Fast waveform scroll in vinyl
mode / aggresive pitch bend
in vinyl mode o
30 VINYL Toggle vinyl mode per deck -
Overview
# INPULSE 500 CONTROL FUNCTION
1 MASTER OUT (UNBALANCED) TRS or 1/4” master output (unbalanced)
2 MASTER OUT (RCA) RCA master output
3 MIC IN (BALANCED) Microphone TRS or 1/4” input (balanced)
4 AUX IN Auxiliary RCA & mini-jack or 1/8” input
5 USB Connect PC via USB connection
14 HEADPHONES 1/4” & 1/8” headphone output
Overview
1 2 3 4
6
5
