Hercules HCB42B User Manual

Page 8 For technical questions, please call 1-888-866-5797. Item 57319
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Release Lever 1
2 Cam 1
3 Cylindrical Pin 1
4 Spring Board 1
5 Screw 3
6 Lever Base 1
7 Ball Bearing 1
8 Front Housing 1
9 Pendulum Fork 1
10 Shaft Cover 1
11 Ball Bearing 1
12 Spindle 1
13 Connector 1
14 Spring 1
15 Washer 1
16 Orientation Sleeve 1
17 Compression Spring 2
18 Clutch Lining 1
19 Retaining Ring 1
20 Revolve Shaft 1
21 Dustproof Cover 1
22 Flange Assembly 1
23 Self Tapping Screw 2
24 Right Cover 1
25 Self Tapping Screw 4
26 Left Cover 1
27 O-Ring 1
Part Description Qty
28 Retaining Ring 1
29 Ball Bearing 1
30 Washer 1
31 Counterweight Piece 1
32 Center Cover 1
33 Washer 1
34 Fan 1
35 Rotor 1
36 Washer 1
37 Ball Bearing 1
38 Control Board 1
48 Light PCB 1
39 Cushion Board 2
40 Cylindrical Pin 1
41 Roller Plate 2 1
42 Rubber Pin 2
43 Left Housing 1
44 Trigger 1
45 Retaining Ring 1
46 Self Tapping Screw 6
47 Right Housing 1
48 Light PCB 1
49 Stator Assembly 1
50 Screw 2
51 Baffle 1
52 Rubber Pin 2
53 Board 1
