PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Power Head Handle 1
2 Head Cover 1
3 Baffle 1
4 Outlet Muffler Sponge 1
5 Outlet Cover A 1
6 Intake Muffler Sponge 2
7 Air Duct Muffler Sponge 1
8 Motor Muffler Sponge 1
9 Motor Assembly 1
10 Air Duct Seal Ring 1
11 O-ring 1
12 Motor Sealing Gasket 1
13 Pull Ring 1
14 Elastic Strap 1
15 Ring Cover 1
16 Ring Cover Seal 1
17 Ground Lug 1
18 Antistatic Copper Sheet 1
19 Valve Assembly 1
20 Power Cord 1
21 Wire Ramp 1
22 Switch Clamp 1
23 Servo Motor Power Switch 1
24 Cooling Air Outlet Muffler Sponge 1
25 Outlet Cover B 1
26 Top Cover Muffler Sponge 1
27 PCBA 1
28 Switch Indicator PCBA 1
29 Control Panel 1
30 Suction Control Knob 1
31 Power Switch 1
32 PTA Assembly 1
33 Valve Seat Seal Gasket 1
34 Seal Strip 1
35 Filter Mount 1
36 Float Seal 2
37 Float 2
Part Description Qty
38 Flat Cage 2
39 Filter 2
40 Wheel Cap 2
41 Wheel 2
42 Axle 1
43 Wheel Support 1
44 Sleeve 2
45 Right Sleeve Assembly 1
46 Handle 1
47 Power Cord Hanger 1
48 Left Sleeve Assembly 1
49 Tank 1
50 Clip 2
51 Vacuum Port Cover 1
52 Vacuum Port 1
53 Hose W/Step Adapter 1
54 Foot Support 2
55 Locking Swivel Caster 2
56 Handle Dam-Board 2
57 Accessory Bag 1
58 Extension Wands 2
59 Floor Nozzle 1
60 Elbow Wand 1
61 Crevice Nozzle 1
62 Power Tool Adaptor 1
63 Disposable Bag 1
64 Round Brush 1
101 Screw ST 5.28*25 14
102 Screw ST 4.55*19 15
103 Screw ST 3.12*12 2
104 Screw ST 3.63*13 7
105 Screw ST 4.55*16 12
106 Screw ST 3.63*10 6
107 Nut 2
108 Spring Washer 2
109 Screw ST 4.55*25 4
