Hercules HE028 - Setup - before Use; Functional Description

Page 4 For technical questions, please call 1-888-866-5797. Item 58966
SETUP - BEFORE USE:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the appliance off and unplug the appliance from its
electrical outlet before performing any procedure in this section.
Note: For additional information regarding the parts listed in the following pages,
refer to the Assembly Diagram near the end of this manual.
FUNCTIONAL DESCRIPTION
CAUTION
To prevent injury:
1. Risk of fire. Do not
exceed 15 Amps.
2. Risk of injury. When
appliances connected to
this receptacle are turned
on, the Dust Extractor will
turn on automatically.
23k
1. Handle
2. Power Switch
3. Suction Control Knob
4. 120VAC Outlet
5. Automatic Filter Cleaning Button
6. Vacuum Port
7. Accessory Bag
8. Floor Nozzle
9. Crevice Nozzle
10. Dust Bag
11. Hose
12. Extension Wands
13. Elbow Wand
14. Power Tool Dust Adaptor
15. Round Brush
16. HEPA Filters
4
1
2
3
5
6
7
8
9
10
12
13
14
15
16
AUTOMATIC FILTER CLEANING
11
