Page 14 For technical questions, please call 1-888-866-5797. Item 57363
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Spindle Lock 1
2 Self-Locking Spring 1
3 Gear Box 1
4 O-Ring 1
5 Self-Locking Pin 1
6 Bearing, 6000-2RS 1
7 Rubber Pin 1
8 Retainer,14MM 1
9 Large Gear 1
10 Retainer, 40MM 1
11 Wave Washer 1
12 Bearing, 6203-LLU 1
13 O-Ring 1
14 Front Cover 1
15 Screw, M5 x 17 4
16 Dust-Proof Cover 1
17 Spindle 1
18 Key, 4 x 4 x 12 1
19 Wheel Guard, Ø180/black 1
20 Flange 1
21 Flange Nut 1
22 Screw, ST4.8 x 37 4
23 Auxiliary Handle 1
24 Nut, M8 x 1 1
25 Small Gear 1
26 Dust-Proof Washer 1
27 Rectangular Rubber Ring 1
28 Bearing, 6301-LLU 1
29 Dust-Proof Ring 1
Part Description Qty
30 Bearing Washer, Ø22 1
31 Retainer, 37mm 1
32 Rotor 1
33 Retainer 1
34 Bearing, 608-V1 1
35 Bearing Bushing 1
36 Air Deflector 1
37 Screw, ST5 x 65 2
38 Stator 1
39 Motor Housing 1
40 Label 1
41 Screw, ST4 x 14 2
42 Right Brush Cover 1
43 Brush Assembly 1
44 Brush Holder 2
45 Coil Spring 2
46 Right Handle 1
47 Screw, ST4.2 x 20 2
48 Trigger Assembly 1
49 Screw, ST4 x 16 1
50 Cord Sleeve 1
51 Power Cord 1
52 Left Handle 1
53 Screw, ST4 x 14 2
54 Brush Assembly 1
55 Left Brush Cover 1
56 Wheel Guard, Ø230/black 1
57 Lower Plate 1
58 Wrench 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 792363573634 when ordering parts.
