Speaker x2 Product manual x1 5M speaker cablex 2
Note:Always allow at least one-half inch
between a wall stud and the speaker cutout
or the locking tabs will not be able to swivel
into place.
Connect the speaker wires to the speaker.
Replace the metal grille.
Cut the drywall
Screw down each of the four Phillips head screws.
The locking tabs will swivel into place and secure
the unit to the rear surface of the drywall.Put in the
strips of adhesive to secure the grille.
1
3
2
4
1.Only for：HCS418\HCS418BT\HCS528\HCS528BT\HCS818\HCS818BT
PACKAGE CONTENT
INSTALLATION GUIDE
4
