hergom SERE 70 - 1 - INTRODUCTION; 1.2 - HOT AIR OUTLET OPTIONS

1 - INTRODUCTION
IMPORTANT! All local regulaons, including those
that refer to naonal or European regulaons,
must be applied when installing this device.
NOTE: When installing any type of insulaon to
safeguard the heat cover, take the following
obligatory recommendaons into account:
• The insulaon must never come into contact
with the device; this would prevent the transfer
of heat and the displacement of the hot air to
the top of the hood.
• Leave a minimum distance of 7 cm between
the insulaon and the appliance.
The way the Compact SERE is installed will have
a decisive eect on safety issues and its correct
operaon.
It is important to install the replace correctly.
To ensure your Compact SERE replace and the
chimney is installed correctly, it should be installed
by a professional.
The Compact SERE provides heat by radiaon;
directly heang walls, ceilings...
and by forced air convecon, thanks to the fans
installed.
TOP GRILLE AIR FLOW
This is the STANDARD air exit. Air enters through
the lower secon, “A”, and the internal fan forces
the hot air through the top secon “B”.
AIR FLOW THROUGH THE HOOD
This opon is compable with the one menoned
above.
Brick hoods must include holes at the boom and at
the top. These gaps can be covered by ornamental
grilles to facilitate the ow of air. Cold air enters
through the lower secon, “C” and exits through
the upper secon “D” (take into account that your
Compact SERE Fireplace provides most of its heat
by convecon). If the venlaon holes in the hood
are not large enough, the device may be damaged
if it is unable to dissipate the heat.
IMPORTANT! The minimum air intake gap
recommended is 200cm² of free passage through
the grille.
The air input grilles in the hood must be located in
such a way that they cannot be blocked.
For further informaon on the correct installaon
of the device, please see the Manual for the
Professional Installer.
1.2 - HOT AIR OUTLET OPTIONS
1. Chimney pipe
2. Hot air grille
3. Cold air grille
4. Forced convecon outlet
