Hermann Supermaster 28 E - Chimney Connections SUPERMASTER E (Natural Draught)

15
Installation
for the technician
Chimney connections
SUPERMASTER E (natural draught)
Place here all necessary
advices according to national rules about
CHIMNEY CONNECTIONS of OPEN chamber boilers
FLUE
NO YES
These diagrams are
to explain the most
important ITALIAN
laws concerning
chimney connections
(for EXEMPLE
purpose only)
PRODUCTS TEST POINT
2500 mm MAX
SLOPE
min 3%
2 x d
min
d
