EQUIPMENT SPECIFICATIONS
Description: EUREKA Automatic Colorant Dispenser
Capacity: Max 24 canisters, 5 liters and 3 liters
Pumps: Each circuit to be used with water or glycol based colorants
uses a dedicated progressive cavity pump consisting of a
hardened and chromed metal rotor with increased abrasion
resistance and a stator made from Viton elastomer. The
materials used for solvent based colorants are different.
Pump speed: Variable based on colorant and quantity to be dispensed.
Maximum speeds per circuit are 0.3 liters/min (A-450) and
0.6 liters/min (A-460)
Nozzle cleaning: Software driven colorant pull-back system implemented at the
end of each dispense, which draws colorant slightly into the
nozzle and minimizes dripping and drying in conjunction with
an automatic humidifying nozzle cap.
Colorant agitation: Individual 24 VDC agitation motors installed on the bottom of
each canister and with programmable timing.
Can sensor: Optional reflective-photocell.
Power supply: Switching power supplies with input from 110 to 240 VAC, 50
Hz or 60 Hz frequency and output at 24 VDC and 67 VDC.
16 Canister 24 Canister
Dimensions: Height 47” (119 cm) 47” (119 cm)
Width 37” (94 cm) 55” (140 cm)
Depth 26” (66 cm) 35” (90 cm)
Weight 400 lbs. (181 Kg) 550 lbs. (250 Kg)
Shipping dimensions: Height 62” (157 cm) 62” (157 cm)
Width 40” (102 cm) 60” (152 cm)
Depth 30” (76 cm) 40” (102 cm)
Weight 500 lbs. (227 Kg) 650 lbs. (295 Kg)
