19
RES
At “RES”, fuel will flow from the reserve
fuel supply to the carburetor. Turn the valve
“RES” by aligning the mark (1) below the
“RES” (4) on fuel valve with the punch mark
ON
At “ON”, fuel will flow from the tank to the
carburetor. Turn the valve “ON” by
aligning the mark (1) below the “ON” (3)
on fuel valve with the punch mark on the
side cover.
(3) ON Position
3
1
(4) RES Position
4
1
on the side cover. Use the reserve fuel only
when the main supply is exhausted. Refill
the tank as soon as possible after switching
to “RES”. The reserve fuel supply is 1.4
litres (usable).
1. To unlock fuel tank lid, lift the key hole cover
(1), insert key (2) turn it clockwise and lift
open the lid (3).
FUEL TANK
Fuel tank capacity is 9.0 litres (minimum)
including usable reserve supply of 1.4 litres.
