HEADLAMP ADJUSTMENT
3. Adjust the headlamp beam by loosening
the bolt (1) and moving the headlamp
unit forward and backward for correct
focus adjustment.
Headlamp is preset. However in case of
adjustment required, please follow the steps
as given below:
1. Headlamp adjustment is done by the
loosening the bolt (1) located below the
headlamp.
2. Park the motorcycle on level ground.
An improperly adjust headlamp may
blind oncoming rider/driver or it may fail
to light the road for a safe distance.
1
Check the front forks by locking the
front brake and pumping the front fork
up and down vigorously. The suspens-
ion action should be smooth and there
should be no oil leakage.
Check the rear shock absorber by
pushing hard downwards on rear grip
while the motorcycle is not parked on
stand. The motorcycle is action should
be smooth and there should be no oil
leakage.
67
(1) Adjusting bolt
