68
(1) Shock absorber adjustment tool
(A) Stiffer
(B) Softer
B
A
1
1. Raise the front wheel off the ground.
2. Remove the speedometer cable (1) by
pressing the tab (2) & then pull out the
cable.
Drum Type
In direction A stiffer.
In direction B softer.
NOTE
Always adjust both the rear shock absorber
to the same position. Use the rear shock
absorber adjustment tool (Pin Spanner) (1)
available in the tool kit (1)
