(3) Front brake cable (4) Brake arm
(1) Speedometer cable (2) Tab
(5) Front brake adjusting nut (6) Axle nut
6
Switch on the ignition, rotate the front wheel
and see if speedometer needle is working.
56
Axle nut torque 5.5 kgf-m.
3. Disconnect the brake cable (3) from
brake arm (4) by removing the front
brake adjusting nut (5).
4. Remove the axle nut (6).
5. Remove the axle then remove the wheel.
69
