HERO IGNITOR - REAR WHEEL REMOVAL

1. Raise the front wheel off the ground.
2. Remove the speedometer cable (1) by
pressing the tab (2) & then pull out the cable.
4. Remove the axle then remove the
wheel.
3. Remove the axle nut (3).
5. Assemble in reverse order of removal.
Axle nut torque 5.5 kgf-m.
Disc Type
(1) Speedometer cable (2) Tab (3) Axle nut
1. Raise the rear wheel off the ground.
2. Remove the rear brake adjusting nut (1)
and disconnect the brake rod (2) from the
brake arm (3) by pushing down the brake
pedal. Disconnect the brake stopper arm
(4) from the brake panel (5) by removing
split pin (6) and lock nut (7).
3. Remove the axle nut (8) and pull out
the axle (9). Remove the wheel.
REAR WHEEL REMOVAL
