Axle nut torque : 5.5 kgf-m
Brake stopper arm nut torque : 2.2 kgf-m
Always replace used split pins with new ones.
(8) Axle nut (9) Axle
(1) Rear brake adjusting nut (2) Rear brake
rod (3) Brake arm (4) Brake stopper arm (5)
Brake panel (6) Split pin (7) Lock nut
Do not put water inside the muffler
during washing. It is advisable to put a
cover over the Exhaust pipe to avoid
water entering the muffler.
71
Adjust the brake (page 59).
headlamp
motorcycle.
Our authorised dealership take all
above mentioned precautions like
recommended detergents and usage of
muffler caps/plugs during wash to
ensure quality wash.
