HERO IGNITOR - LEFT HANDLEBAR CONTROLS

LEFT HANDLEBAR CONTROLS
1
2
3
Press the push switch to operate the pass
lamp.
When Tripmeter is selected long press the
Reset button to reset Tripmeter to zero.
The Odometer can be displayed from "0 to
999999" kms.
Push the Select button (2) to select
Odometer, or Tripmeter. The Tripmeter
can display upto 99999.9 kms. If the
Tripmeter exceeds "99999.9" kms it will
return to "0.0" kms automatically.
The Tripmeter (3) shows distance traveled
since trip meter was reset last time.
x1000r/min
8
7
6
5
4
F
3
2
1
0
9
10
11
12
N
SELECT
RESET
AM
PM
km
km.
km..
3
1
2
1
15
1. Pass lamp switch
2. Headlamp switch
marked by white dot.
