HERO IGNITOR - FUSE REPLACEMENT

65
Fuse Type : Blade fuse
Refer to the safety precautions on (page 38).
Spare fuse : (3) 15A, 10A
Fuse Box (1) Location : On battery band.
In circuit fuse : (2) 15A, 10A
FUSE REPLACEMENT
Fuse Type : Blade fuse
Spare fuse : (6) 20A
Start Mag. Switch (4)
In circuit fuse : (5) 20A
Location : Below start mag. switch
Location : Inside left side cover
2
3
6
4
1
Location : On battery band behind the fuse
box (1).
5
