POWER SUPPLY
The unit is designed to plug into a normal GPO.
If there is not a convenient outlet available, then one should be installed either
within the cupboard or in close proximity.
NOW TO INSTALL THE AIRHANDLER
Sit the A/H on the rails and adjust its position as per the cutting out template, the
front being flush with back of front panel when fitted.
The surplus pipe can now be cut off, the pipe angles generally adjusted to line up
with the A/H nipples.
Unscrew both flare nuts from the A/H and knock out the sealing bonnets, before
slipping them onto their respective tubes. Now flare both tubes, and connect them
to the A/H. Tighten both nuts firmly. See fig. 9.
